Small Pesticides Plastic Bottle Making Machine , 50ml - 350ml Bottle Blow Machine

পণ্যের বিবরণ:

Place of Origin:	China
পরিচিতিমুলক নাম:	TONGDA
সাক্ষ্যদান:	CE& ISO9001& Bundersrepublik deutschland patents
Model Number:	HTSII-3L

প্রদান:

Minimum Order Quantity:	1set
মূল্য:	Negotiable
Packaging Details:	20GP
Delivery Time:	60 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50SETS/MONTH

যোগাযোগ

বিস্তারিত পণ্যের বর্ণনা

Screw:	70mm	Output of HDPE:	70kg/hr
Suitable material:	PE/PP/LDPE/HDPE	Max. volumen:	1000 ml
Station:	Double stations	View strip:	Optional
Color:	White/Blue/Yellow/Orange
লক্ষণীয় করা:	bottle blow moulding machine , plastic bottle manufacturing machine

50ml 100ml 200ml 350ml small plastic pesticides bottles Blow Moulding Machines HTSII-3L

double station automatic bottle molding machine SRB60-1C is widely used in PVC plastic bottle and container making field, sport joyshaker water bottle making field, detergent liquid soap bottle making field, small toy parts field, also used for other small round or square pvc containers.

Extrusion blow molding machine technical specification:

Model		HTSII-3L
Max. Product Volume	(L)	0.35L
Dry cycle	(pc/h)	800*2
Screw Diameter	(mm)	70/80
Screw L/D ratio	(L/D)	25
Screw drive power	(KW)	22/30
Screw heating capacity	(KW)	4.2/8
No. of heating zone	(ZONE)	3/4
Max. Output of HDPE	(Kg/hr)	70/110
Oil pump drive power	(KW)	11
Clamping force	(KN)	80
Platen distance	(mm)	160~320
Mold moving stroke	(mm)	500
Max. Size of Mold(W*H)	(mm)	450*250
Max. Die diameter	(mm)	30/45
Die heat capacity	(KW)	4.3
No. of heating zone	(ZONE)	13
Central distance of Quad head	(mm)	70/100
Blowing pressure	(Mpa)	0.6
Air volume	(M3/MIN)	0.4
Cooling water pressure	(Mpa)	0.2~0.3
Water consumption	(L/MIN)	80
Size of machine ( LWH)	(m)	3.22.72.5
Weight of machine	(TON)	8

Extrusion blow molding machine technical feature:
The electronic control system: Japan's Mitsubishi PLC computer and human-machine interface (English or Chinese) control, color touch-screen operation. All the process set to change, retrieval, monitoring, troubleshooting and other functions are implemented on the touch screen, no point of contact with the working principle, components and durable.
The hydraulic system: proportional pressure control, with imported brands Yuken hydraulic components, stable and reliable.
The plasticizing system: efficient plastics mixing screw, to ensure plasticizing full uniform.
The speed control system: VVVF + alloy steel and hard gear reducer, speed stable, low noise, durable.
The opening and closing mold, mold transfer system: beam arm, three position, center locking clamping mechanism, to ensure long-term use. Clamping force balance, no deformation, the use of body translation mode (ball linear guide), high precision, low resistance, fast.
Blowing the needle holder: blow the whole Square-type needle holder, a solid does not shift to ensure a smooth incision products.

Extruson blow molding machine suppliers of main parts:
a) Hydraulic Parts

Name	Supplier
Oil Pump	PARKER or SUNNY, America
Valve	YUKEN or SUNNY
Hose, Joint	PARKER SIR
Sealer	Top DZ Europe

b) Electrical Parts

Name	Supplier
Microcomputer Control System	MITSUBISHI PLC, Japan
Touch Screen	HITECH color screen, Taiwan
Temperature Controller	MITSUBISHI, Japan
Conductor	SCHNEIDER
Air Switch	SCHNEIDER
Motor	SIMENS BEIDE Asynchronous Motor
Power Resource	MEAN WELL, Taiwan
Inverter	MITSUBISHI

c) Pneumatic Parts

Name	Supplier
Solenoid Valve	FESTO, Germany
Cylinder	FESTO, Germany

Extrusion blow molding machine installation, commissioning and training:
If the buyer needs seller to send technicians to workshop for supervising the erection and start-up, seller must support and send sufficient number of technicians and keep duration of stay in workshop. Usually it’s about 3~5 days in this duration. The first day is that when our technician is at the airport to factory of buyer. And from the first day, the buyer has to pay US$80 per day. And all accommodation, visa application & air ticket will be born by the buyer.
Small Pesticides Plastic Bottle Making Machine , 50ml - 350ml Bottle Blow Machine 3
